[DIGITAL LINK menu]

Displays the setting menu of Digital Interface Box.
Select [DIGITAL LINK menu] with and press

Note

●

This function can only be selected when the

Panasonic device that supports DIGITAL LINK output

(ET-YFB100G, ET-YFB200G) is connected to a

DIGITAL LINK IN terminal of DIGITAL LINK Terminal

Board and its power is on.

●

For details, refer to the manuals of the devices that

support DIGITAL LINK output.

■

[Extron XTP]

Set to [On] when connecting XTP Transmitter made by

Extron to DIGITAL LINK IN terminal of DIGITAL LINK

Terminal Board.

●

For more details on Extron, visit the following web

site.
http://www.extron.com

Note

●

When this item is set to [On], [Administrator account

settings] needs to be set.

■

[Auto display name]

Sets whether to change the display name automatically.

[Off]:

The display name is not changed automatically.

[On]:

Changes the display name automatically in

accordance with the set point of the display ID.

■

[Display name]

The name of the Display that is shown on the network

can be changed.

Note

●

The name can be changed only when [Auto display

name] is set to [Off].

●

Display ID is not reset to default with [Network

settings] - [Reset].

■

[USB memory network settings]

Sets whether to permit the network setting using the

USB memory device. (see page 162)

[Permit]:

Permits USB memory network settings.

[Prohibit]:

Prohibits USB memory network settings.

Note

●

This function is set to [Permit] as factory default.

●

Once the network setting is done with USB memory

device, this function is set to [Prohibit].

■

[LAN control protocol]

Select the LAN control protocol.

[Protocol 1]:

Control with the Panasonic Display sequence.

[Protocol 2]:

Control with the sequence that is compatible with

Panasonic Projector.

Note

●

For PJLink and WEB browser control, the operation is

possible regardless of the setting.

●

When operating the “Multi Monitoring & Control

Software”, select [Protocol 2].

■

[Reset]

You can reset the network setting to the factory default

of the Display.
Select [Yes] with and press .

Network settings

Reset

Yes

Note

●

The settings for [NTP synchronization], NTP server

and [Time zone] will be reset to the factory default.

●

When [Security password] - [Security password] is set

to [On], it is necessary to input the password when

commanding [Reset].
