Press Page 160
Page 160
160
English
7
Press
8
Select [Execute] with
and press
EQ2-001
EQ2-002
EQ2-004
EQ2-005
EQ2-014
EQ2-006
EQ2-041
EQ2-009
192.168. 0. 1
192.168. 0. 2
192.168. 0. 4
192.168. 0. 25
192.168. 0. 31
192.168. 0. 7
192.168. 0.124
LAN data cloning
Status
Execute
Display name
IP address
Select display
Off
Write protect
Note
●
Data cannot be copied to the display for which
[Write protect] is set to [On]. Set this to [On] to
prevent [LAN data cloning] from being performed
mistakenly when data copy is not necessary.
●
Once [LAN data cloning] is performed, [Write
protect] is set to [On].
9
A confirmation window appears.
Select [Execute] with and press
All data for the selected displays will be changed.
Are you sure you want to execute?
Execute
Return
LAN data cloning
Data copy to the display starts.
LAN data cloning
Cloning in progress, please wait.
DO NOT unplug your Display!
10
The exit screen appears.
The blue mark on the list shows the data has been
copied successfully. The red mark shows failure.
If the red mark appears, check the LAN cable
connection or power status of the display of the copy
destination.
EQ2-001
EQ2-002
EQ2-004
EQ2-005
EQ2-014
EQ2-006
EQ2-041
EQ2-009
192.168. 0. 1
192.168. 0. 2
192.168. 0. 4
192.168. 0. 25
192.168. 0. 31
192.168. 0. 7
192.168. 0.124
192.168. 0.211
LAN data cloning
Status
Cloning finished.
Display name
IP address
If the data copy has finished, the message appears
on the display of the copy destination.
Cloning finished. Please turn off the power.
11
Press the power button on the remote
control to turn the power off, and
then turn the power on. Or remove
the power plug from the outlet once,
wait for 30 seconds or more, and then
insert the power plug.
The copied content is applied to the display.
