Copying data to other display via lan, Enter the cloning password, and then press Page 159: Display [setup] menu pressing
Page 159: Display [setup] menu pressing
159
English
6
Enter the cloning password, and then
press
Data cloning screen is displayed.
7
Select [
USB memory → Display
] with
and press
Select copy type
Display → USB memory
USB memory → Display
8
Select [Yes] with and press
Data cloning to the display starts.
Data from USB memory
Do you copy the data ?
Yes
No
The following message is displayed after data
cloning has finished.
Cloning finished. Please turn off the power.
9
After data cloning has finished,
remove the USB memory device from
the USB terminal.
10
Press the power button on the remote
control to turn the power off, and
then turn the power on. Or remove
the power plug from the outlet once,
wait for 30 seconds or more, and then
insert the power plug.
The cloned content is applied to the display.
●
When USB memory is not removed in the step 9,
the [Cloning password] screen is displayed.
Copying data to other display via
LAN
1
Display [Setup] menu pressing
2
Select [Options] with and press
The following display appears.
Display information
Options
Software licenses
Cloning password
USB data cloning
Security password
LAN data cloning
Output log data
Shipping
3
Select [LAN data cloning] with
and press
[Cloning password] screen is displayed.
4
Enter the cloning password, and then
press
[LAN data cloning] screen is displayed.
5
Select [Select display] with and
press
Displays on the same subnet are listed.
LAN data cloning
Select display
Execute
Write protect
Off
Status
Display name
IP address
6
Select the display to copy the data to
with and press <
VOL +
>.
Select all the displays to copy the data to.
EQ2-001
192.168. 0. 1
192.168. 0. 2
192.168. 0. 4
192.168. 0. 25
192.168. 0. 31
192.168. 0. 7
192.168. 0.124
192.168. 0.211
EQ2-002
EQ2-004
EQ2-005
EQ2-014
EQ2-006
EQ2-041
EQ2-009
Select display
Please check the display to register.
Check
Display name
IP address
