Panasonic TH-86EQ2W 85.6" 4K Digital Signage Display - Manual (Page 125)

125
English
■
Music playback
Music content is played back at the time set with the
schedule data.
Playback files in the following formats are supported.
Music
Extension Codec Format
mp3 MPEG-1/2
Audio Layer-3
AAC(LC)
Sample rate:
Maximum 48 kHz
Channel: Maximum 2 ch
Bit rate:
Maximum 320kbps
wma WMA
Note
● Some files may not be played back even if they are
supported formats described above.
● If incompatible music content is scheduled, the music
content is not played back.
● Music content can be played back only with the [USB]
or [Internal Memory] input.
● Video content and music content cannot be played
back simultaneously. If 2 pieces of content are set
for playback at the same time, video content takes
priority.
● If video content starts to be played back while music
content is being played, the playback of the music
content stops.
● When playing back music content after playback of
video content has finished, the playback starts from
the beginning of the music content.
● Music content cannot be played back in
synchronization with other displays.
● Several minutes of preparation time are added in
switching music content.
■
Input switch
The input is switched to the specified input at the
time set with the schedule data. When the set time
has passed, the [USB] or [Internal Memory] input is
restored.
Note
● The input is switched even if no signal is present at
the input switch destination.
● When the input is switched, the input display does
not appear.
■
Power control
The power is turned on/off at the time set with the
schedule data.
Note
● If the power is turned off during schedule play mode,
the unit enters the schedule standby mode.
● The standby electricity will be more than normal
during the schedule standby mode.
● Some of the main unit functions in schedule play
mode remain invalid during the schedule standby
mode.
● The power-on schedule operates one minute before
the specified schedule time.
● If the unit enters the schedule standby mode after
one minute before the power-on schedule, the power
is not turned on at the specified time by the schedule
playback function.
● The power-on operation by [Schedule play function]
does not work in standby states other than the
schedule standby mode.
■
Multi screen display setting of the multi
display
Sets the following for playback content.
● Plays in the single playback mode.
● Plays in the synchronized playback mode.
● Changes the setting of [Multi display settings] -
[Multi screen display] of the main unit.
In [Individual play] mode
Content is played only on one display.
In [Synchronize play] mode
Content is played on multiple displays in
synchronization.
To play back in the synchronized playback mode, set
the following for correct operation.
• Set [USB media player] to [Enable].
• Set [Schedule play function] to [Enable].
• Set [Synchronize display] to [On].
• For [Parent or child setting], set one display with
reference time to [Parent] and other displays to
[Child].
Note
● The operations of the single playback mode and the
synchronized playback mode are different from those
of Single Media Player and Multi Media Player of the
existing USB media player.
● For playback in the synchronized playback mode,
approx. 5 seconds of preparation time are added in
switching content.
● To perform the synchronized playback with multiple
displays, set the [Synchronize display] function to
[On], and set the same time for all the displays for
playback.
● If the time is not synchronized correctly with
[Synchronize display] set to [On], the unit may not
operate properly. Confirm the operation conditions of
[Synchronize display]. (see page 73)
● If [Multi display settings] - [Multi screen display]
is specified in the schedule data of “Content
Management Software”, the setting is switched to
the specified multi screen display. The setting of
[Multi screen display] cannot be changed during the
specified schedule playback. When the specified
schedule has finished, the setting of [Multi screen
display] is restored to the state before setting.
