DIVA T/A ISDN Modem User’s Guide
◆ Page 34
The DIVA Terminal Adapters Program for Windows 95/98/NT
The following table describes the action that each icon performs. To make sure you can see
all the icons, select ‘Toolbar’ from the ‘View’ menu, then enable all the options in the list.
Click or Select To perform this Action
File >
Configure Opens the Configuration Tool for the active profile, allowing you modify
your ISDN settings. See “Configuring a Profile using the Configuration Tool”
on page 37 for more information.
File >
Wizard Launches the Configuration Wizard, which takes you step-by-step through
the configuration of your ISDN settings. Changes are saved to the active
profile. Not all settings can be configured through the Configuration
Wizard. If you wish to modify all parameters, configure the profile manually
using the Configuration Tool (see next command).
File >
Configure
Profiles Opens the Profiles window. The Profiles window allows you to edit and
rename any of the three profiles. This is also where you set the active profile.
File >
Download
Firmware Downloads new Firmware. See “Updating Firmware” on page 79 for more
details.
File >
Factory Reset Resets your DIVA T/A to the original factory settings.
File >
Details Displays a panel that contains details about your DIVA T/A. Use it if you need
to determine details about your configuration (such as your firmware
version).
File >
Delete Deletes the currently selected device.
File >
Import Profiles Imports a profile file (.PRF), which contains three profiles plus other
configuration parameters. The file is imported to the selected device.
Files >
Export Profiles Exports the device configuration, which includes three profiles, to a profiles
file (.PRF). Before updating firmware, it is strongly recommended that you
export your current profiles.
View >
Refresh Refreshes information about the selected device.
Tools >
Connect Opens the ‘Make New Connection’ dialog box. Configured Dial-Up
Networking connections are available from the drop down list. If you are
using Windows NT, you can use this option to run RAS.
Tools >
Modems Opens the ‘Windows Modem Properties’ box.
Tools >
Terminal Launches a terminal emulation program, from which you can use AT
commands on your device. This is primarily used for troubleshooting.
