10 Appendix
10.1.2 Parameters
10-12
Pn170
2 Tuning-less Function Related Switch 0000 to 2411 − 1401 − – –
Pn190 2 Reserved (Do not change.) – – 0010 – – –
Pn200 2 Reserved (Do not change.) – – 0100 – – –
Pn205 2 Multiturn Limit Setting 0 to 65535 1 rev 65535 After restart Setup 4.5.6
Pn207
2 Position Control Function Switch 0000 to 2210 − 0010 After restart Setup −
Pn20A 4 Number of External Scale Pitch 4 to 1048576
1
pitch/rev
32768 After restart Setup 8.3
Pn20E 4 Electronic Gear Ratio (Numerator)
1 to
1073741824
1 4 After restart Setup 4.2.4
Pn210 4 Electronic Gear Ratio (Denominator)
1 to
1073741824
1 1 After restart Setup 4.2.4
Pn212 4 Encoder Output Pulses
16 to
1073741824
1 P/rev 2048 After restart Setup 4.2.6
Pn216 2 Reserved (Do not change.) – – 0 – – –
(cont’d)
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classi-
fication
Reference
Section
Tuning-less Function Selection
When
Enabled
Classification
Reference
Section
0 Disables tuning-less function.
After restart Setup 5.2
1 Enables tuning-less function.
Control Method during Speed Control
When
Enabled
Classification
Reference
Section
0 Uses as speed control.
After restart Setup 5.2
1
Uses as speed control and uses the host controller for
position control.
Rigidity Level
When
Enabled
Classification
Reference
Section
0 to 4 Sets rigidity level. Immediately Setup 5.2
Load Level
When
Enabled
Classification
Reference
Section
0 to 2 Sets load level. Immediately Setup 5.2
4th 3rd 2nd 1st
digit digit digit digit
n.
Reserved (Do not change.)
Reserved (Do not change.)
Reserved (Do not change.)
/COIN Output Timing
Reference
Section
0 Outputs when the position error absolute value is the same or less than the
positioning completed width (Pn522).
4.6.6
1 Outputs when the position error absolute value is the same or less than the
positioning completed width (Pn522), and the reference after position reference
filtering is 0.
2 Outputs when the position error absolute value is the same or less than the
positioning completed width (Pn522), and the position reference input is 0.
4th 3rd 2nd 1st
digit digit digit digit
n.
