10 Appendix 2 Parameter Cross Reference
YASKAWA PL.A1000.01 G5 to A1000 - Product Transition Guide 55
Motor Protection
Function
Motor Protection
Selection*
L1-01 1 ─ ─ *For setting details, see the description for E1-02 in G5
Motor Protection Time
Constant
L1-02 8.0 min. L1-02 1.0 min. ―
Momentary Power
Loss Process
Momentary Power
Loss Operation
L2-01 0 L2-01 0
L2-01 L2-01
0: Disabled 0: Disabled
1: Enabled 1: Enabled
2: CPU enabled run 2: CPU enabled run
─ 3: KEB operation
─
4: KEB deceleration as long as
CPU has power.
─ 5: KEB deceleration to stop.
Momentary Power
Loss Ride-Thru Time
L2-02 0.7* L2-02 * *Depends on drive capacity.
Momentary Power
Loss Minimum
Baseblock Time
L2-03 0.5* L2-03 * *Depends on drive capacity.
Momentary Power
Loss Voltage Recovery
Ramp Time
L2-04 0.3* L2-04 * *Depends on drive capacity.
Undervoltage
Detection Level
L2-05 190 V* L2-05 190 V*
*Double this value for 400 V classs drives. Multiply by 3 for 600
V class. If E1-01 is set lower than 400, then set 350 V for A1000.
KEB Deceleration Rate L2-06 0.0 L2-06 0.0 s ―
Stall Prevention
Function
Stall Prevention
Selection during
Acceleration
L3-01 1 L3-01 1
L3-01 L3-01
0: Disabled 0: Disabled
1: General purpose 1: General purpose
2: Intelligent acceleration 2: Intelligent acceleration
Stall Prevention Level
during Acceleration
L3-02 150 % L3-02 150%* *Upper limit is determined by L8-38.
Stall Prevention Limit
during Acceleration
L3-03 50 % L3-03 50% ―
Stall Prevention
Selection during
Deceleration
L3-04 1 L3-04 1
L3-04 L3-04
0: Disabled 0: Disabled
1: Enabled 1: Enabled
2: Intelligent deceleration 2: Intelligent deceleration
3: Enabled
(with braking resistor) 3: Enabled
(with braking resistor)
─ 4: Overexcitation braking
─ 5: Overexcitation deceleration 2
Stall Prevention
Selection during
Running
L3-05 1 L3-05 1
L3-05 L3-05
0: Disabled 0: Disabled
1: Enabled (Decel Time 1) 1: Enabled (Decel Time 1)
2: Enabled (Decel Time 2) 2: Enabled (Decel Time 2)
Stall Prevention Level
during Running
L3-06 160 % L3-06 150 %* *Upper limit is determined by L8-38.
Frequency Detection
Speed Agree Detection
Level
L4-01 0.0 Hz L4-01 0.0 Hz ―
Speed Agree Detection
Width
L4-02 2.0 Hz L4-02 2.0 Hz ―
Speed Agree Detection
Level (+/-)
L4-03 0.0 Hz L4-03 0.0 Hz ―
Speed Agree Detection
Width (+/-)
L4-04 2.0 Hz L4-04 2.0 Hz ―
Operation when
Frequency Reference is
Missing
L4-05 0 L4-05 0
L4-05 L4-05
0: Stop 0: Stop
1: Continue operating at 80%
speed 1: Continue operating at the
level set to L4-06
In A1000, the setting range for the frequency reference when the
reference is lost (L4-06) is 0 to 100 % (default: 80%)
Fault Restart
Number of Auto
Restart Attempts
L5-01 0 times L5-01 0 times ―
Auto Restart Operation
Selection
L5-02 0 L5-02 0
L5-02 L5-02
0: No output 0: No output
1: Outputs during restart 1: Outputs during restart
Parameter Name
G5 A1000 Comments (Gray shading indicates default settings)
No. Default No. Default G5 A1000
