9 Appendix 1 Ratings
YASKAWA PL.A1000.01 G5 to A1000 - Product Transition Guide 25
Table 14 600 V Normal Duty Ratings
600 V Norman Duty
NEC HP 600V NEC Amps
A1000 (C6-01 = 0) GPD515/G5
A1000
Model
CIMR-AU5A
Output Amps Fc kHz
Overload %
Normal Duty
GPD515/G5
Model
CIMR-G5U
Output Amps Fc kHz Overload %
2 2.7 0003 2.7 <1>
<1> The A1000’s default ND (normal duty) carrier frequency is a 2 kHz Swing PWM.
120 51P51 3.5 10 150
3 3.9 0004 3.9 <1> 120 52P21 4.1 10 150
5 6.1 0006 6.1 <1> 120 53P71 6.3 10 150
7.5 9 0009 9 <1> 120 55P51 9.8 10 150
10 11 0011 11 <1> 120 57P51 12.5 10 150
15 17 0017 17 <1> 120 50111 17 10 150
20 22 0022 22 <1> 120 50151 22 10 150
25 27 0027 27 <1> 120 50181 27 10 150
30 32 0032 32 <1> 120 50221 32 10 150
40 41 0041 41 <1> 120 50301 41 10 150
50 52 0052 52 <1> 120 50371 52 10 150
60 62 0062 62 <1> 120 50451 62 10 150
75 77 0077 77 <1> 120 50551 77 10 150
100 99 0099 99 <1> 120 50751 99 2 150
125 125 0125 0125 <1> 120 50900 130 2 150
150 144 0145 0145 <1> 120 51100 172 2 150
200 192 0242 0242 <1> 120 51600 200 2 150
250 242 242 242 <1> 120 — — — —
