Mid-program startup in a point table (FCL 2 function)
U Select the smarT.NC operating mode
U Select the Program Run submode
U Select mid-program startup
U Enter the line number of the machining unit in which you
want to start the program run. Confirm with the ENT key.
Then smarT.NC displays the content of the point table in the
preview window
U Select the machining position where you want to resume
machining
U Press the NC Start key: smarT.NC calculates all factors
required for program entry
U Select the function for approaching the starting position: In a
pop-up window, smarT.NC displays the machine status
required at the startup position
U Press the NC Start button: smarT.NC reestablishes the
machine status (e.g. insert the required tool)
U Press the NC Start button again: smarT.NC moves to the
starting position in the sequence shown in the pop-up
window. As an alternative, you can move separately in each
axis to the starting position
U Press the NC Start button. smarT.NC resumes program run.
