27
Replacing a fuse
Warning! Risk of electrical shock
When replacing a fuse it is possible to touch hazardous live parts.
To avoid the hazard, always power off the unit and disconnect the power cable.
Notice
Use only replacement fuses meeting rated specifications to avoid damage to
the product.
To replace a fuse:
X X Verify power is removed from the module
X X Insert a flat-edge screwdriver into the slot on the fuse holder and turn counterclockwise
to disengage the fuse holder
X X Remove the fuse holder and replace the fuse
X X Re-insert the fuse holder and turn clockwise with flat-edge screwdriver until re-engaged
4
Fuse holder
