Page 113
95
Chapter 5. Gateway Circuits
707023-003
Gateway Circuit 001 (Token Ring - LLC to Ethernet - LLC)
Gateway Circuit 001
LINCS C8.2 Central Control
UPSTREAM CONNECTION
Line:
TRC1
Link Profile:
08 (LLC)
Local SAP:
08
Remote LAN Address:
4000 1111 0000
Remote SAP:
04
DOWNSTREAM CONNECTION
Line:
FET1
Link Profile:
08 (LLC)
Local SAP:
04
Remote LAN Address:
0200 2222 0000
Remote SAP::
04
PF: 1-Menu
3-Def_Dflt 4-Add
5-Delete 7-Back 8-Forw 9-Default 10-Done
Gateway Circuit 002 (Token Ring to LLC to Ethernet - IP)
Gateway Circuit 002
LINCS C8.2 Central Control
UPSTREAM CONNECTION
Line:
TRC1
Link Profile:
07 (LLC)
Local SAP:
0C
Remote LAN Address:
4000 1111 0000
Remote SAP:
04
DOWNSTREAM CONNECTION
Line:
FET1
Link Profile:
09 (TCP/IP)
Remote IP Address:
192 000 222 201
Remote Data Link ID:
4000 2222 0002 04
PF: 1-Menu
3-Def_Dflt 4-Add
5-Delete 7-Back 8-Forw 9-Default 10-Done
Gateway Circuit 003 (Channel to Token Ring - LLC)
Gateway Circuit 003
LINCS C8.2 Central Control
UPSTREAM CONNECTION
Line:
CHP1
Link Profile:
01 (Channel/SNA)
PU Address:
10
DOWNSTREAM CONNECTION
Line:
TRC1
Link Profile:
08 (LLC)
Local SAP:
04
Remote LAN Address:
4000 2222 0000
Remote SAP::
04
PF: 1-Menu 3-Def_Dflt 4-Add
5-Delete 7-Back 8-Forw 9-Default 10-Done
