N0422, F0522, N0622, F0822, N0922, F1222, N1322, F1522
Air, Water or Remote Service Manual
December 2014
Page 46
Options
Vari-Smart
Optional adjustable ice level control (KVS). When
this option is present there is an adjustment post and
an additional indicator light to the right of the four
indicator lights mentioned earlier.
The ultrasonic ice level control allows the user to
control the point that the ice machine will stop making
ice before the bin or dispenser is full.
Reasons for this include:
• Seasonal changes in ice used
• Planning to sanitize the bin
• Faster turnover for fresher ice
• Certain dispenser applications where maximum ice
level is not desired
Use of adjustable ice level control
There are several positions the ice level can be set to,
including Off or Max (knob and label indicators lined
up), where it fills the bin until the standard bin control
shuts the machine off. See the kit’s instructions for
complete details.
Rotate the adjustment post to the desired ice level.
The machine will fill up to that level and when it shuts
off the indicator light next to the adjustment post will
be On.
Note: The maximum fill position is when the arrow on
the knob points to the arrow on the label.
Dispenser applications - Nugget ice only:
Set the adjustment knob arrow to the Norm area
between the green arrows. Select either the first or
second positions as a starting point and adjust as
needed.
