N0422, F0522, N0622, F0822, N0922, F1222, N1322, F1522
Air, Water or Remote Service Manual
December 2014
Page 33
Heat Load, Charge and Condenser GPM
Heat Load - Average heat load for air conditioning
unit sizing
Model
BTUH
N0422, F0522A
5000
N0622, F0822A
7100
N0922, F1222A
10500
N01322, F1522A
16000
Water Cooled Water Use - Condenser Only
Model
GPM @ Supply
Water Temp
GPM @ test
ambient
N0422,
F0522W
.14 @ 50
o
F water .23 @ 70
o
F water
N0622,
F0822W
.21 @ 50
o
F water .40 @ 70
o
F water
N0922,
F1222W
.68 @ 50
o
F water .76 @ 70
o
F water
N01322,
F1522W
.32 @ 50
o
F water .59 @ 70
o
F water
Refrigerant Charge
Model
Series
R-404A (oz)
N0422A,
F0522A
A or D
14
N0422W,
F0522W
A or D
11
N0622A,
F0822A
A or B or D
14
N0622W,
F0822W
A or B or D
11
N0622R,
F0822R
A or B or D
192
N0922A,
F1222A -32
A
18
N0922W,
F1222W -32
A
20
N0922A,
F1222A -3
A
20
N0922W,
F1222W -3
A
22
N0922A,
F1222A
B or D
22
N0922W,
F1222W
B or D
28
N0922R,
F1222R
A or B or D
192
N1322A,
F1522A
A or D
34
N1322W,
F1522W
A or D
18
N1322R,
F1522R
A or D
192
