PATTERN SETUP

PATTERN SETUP
------------------------
PATTERN NO. 1
UNDEFINED
CLR PATTERN CANCEL

BACK
EXIT

Pattern Number

[1~4 ]
Selects Pattern number to edit.
If a selected pattern number is not defined,
"UNDEFINED" will be displayed under selected pattern
number.

Clear Pattern

[CANCEL/OK]
Deletes data in current pattern

Edit Pattern

Starts editing pattern.

EDIT PATTERN

EDIT PATTERN 1
------------------------

MOVE TO START POSITION
[NEAR:START /FAR:CANCEL]

1. Using Joystick, move to start position with appropriate zoom. To start pattern

recording, press NEAR key. To exit this menu, press FAR key.

EDIT PATTERN 1

[NEAR:SAVE /FAR:DELETE]
0/0/x1/N

2. Move camera with controller joystick or run preset function to memorize a path

(often a curved path) in a selected pattern. The total memory size and remaining
memory size are displayed in the form of a bar. Maximum 1200 communication
commands can be stored in a pattern.

3. To save data and exit, press NEAR key. To cancel recording and delete record

data, press FAR key.
