28561AA 15
OPERATION
CHECK POINTS BEFORE OPERATION
• Before power is applied, please check the cables carefully.
• The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading the
DIP switches on the camera.
• If your controller supports multiple protocols, the protocol must be changed to match to that of the camera.
• If you changed the camera protocol by changing the DIP switch, the change will be effective after you reboot the camera.
• Since the operation method can be different for each controller available, refer to the manual for your controller if camera cannot
be controlled properly. The operation of this manual is based on the standard Pelco® Controller.
PRESET AND PATTERN FUNCTION PRE-CHECK
• Check controller or DVR preset and pattern function operation in advance to take advantage of full camera functions when using
controller or DVR.
• Refer to the following table when using a standard Pelco® protocol controller.
< Go Preset > Input [Preset Number] and press [Preset] button.
< Set Preset > Input [Preset Number] and press [Preset] button for more than 2 seconds.
< Run Pattern > Input [Pattern Number] and press [Pattern] button.
< Set Pattern > Input [Pattern Number] and press [Pattern] button for more than 2 seconds.
• If the controller or DVR has no pattern button or function, use shortcut keys with preset numbers. For more information, refer to
“Reserved Preset” in this manual.
