24-port NWay Ethernet Switch User’s Guide
4 Unpacking and Setup
2 2
U
NPACKING AND
S
ETUP
This chapter provides unpacking and setup information for the Switch.
Unpacking
Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items:
♦ One DES-3225G 24-port NWay Ethernet Switch
♦ One 2-port 100BASE-TX Fast Ethernet module preinstalled on front panel (DES-3225GF includes a 1-port
100BASE-FX module preinstalled).
♦ One console cable
♦ Mounting kit: 2 mounting brackets and screws
♦ Four rubber feet with adhesive backing
♦ One AC power cord
♦ This User’s Guide with Registration Card
If any item is found missing or damaged, please contact your local D-Link reseller for replacement.
Installation
Use the following guidelines when choosing a place to install the Switch:
♦ The surface must support at least 3 kg.
♦ The power outlet should be within 1.82 meters (6 feet) of the device.
♦ Visually inspect the power cord and see that it is secured to the AC power connector.
♦ Make sure that there is proper heat dissipation from and adequate ventilation around the switch. Do not place
heavy objects on the switch.
Desktop or Shelf Installation
When installing the Switch on a desktop or shelf, the rubber feet included with the device should first be attached. Attach
these cushioning feet on the bottom at each corner of the device. Allow adequate space for ventilation between the device
and the objects around it.
