Gasboy FuelOmat Payment Terminal User Manual
Page 37
OrPT Manual
27
Figure 3-3. TCP/IP Properties
Table 3-1. TCP/IP Properties
No. Parameter
Name
Required Value
Default Value
1
Obtain an IP address automatically
No (unchecked)
Yes
2
Use the following IP address
Yes (checked)
No
3
IP Address
IP address of the laptop, which
will be used for communicating
with the OrPT.
Note: the first IP segment must
be identical to the rest of the
network devices.
Blank
4 Subnet
mask
255.255.255.0
Blank
5
Default gateway
Leave blank
Blank
6
Obtain DNS server address
automatically
No (unchecked)
Yes
7
Use the following DNS server
Yes (checked)
No
