Comtech EF Data PCB-4000 - Manual (Page 84)

PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–22
A.3.3.2 Ku-Band 1+1 Phase Combined Waveguide and Components Kit – HPOD (KT-0020623)
Table A-11. Kit KT-0020623 BOM
Kit KT-0020623 (see Figure A-10)
Item No. QTY CEFD Part No. Description
1 1
FP-0000414 MOUNTING BRACKET, DUAL VERTICAL SWITCHES, WR75
2 4
HW/3/8SPRINGNUT SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
3 4
HW/3/8-FLT 3/8 WASHER, FLAT, SS
4 4 HW/3/8-SPLIT 3/8 WASHER, SPLIT LOCK, SS
5 4 HW/3/8-16X1BLT 3/8-16 X 1.00 HEX HEAD BOLT, SS
6 1 FP-0000416 SUPPORT BRACKET, TERMINATION
7 2 HW/1/4-FLT 1/4 WASHER, FLAT, SS
8 2
HW/1/4-SPLIT 1/4 WASHER, SPLIT LOCK, SS
9 2 HW/1/4-20X5/8SHCS 1/4-20 X 5/8 SOCKET HEAD CAP SCREW, SS
10 2
SW/WGS28V-75SB SW WAVEGUIDE, WR75, +28V SEALED
11 1
RF-0000024 RF MAGIC TEE, COUPLER, WR-75G, Ku-BAND, 4 WAY
12 3
FP-0020812 WAVEGUIDE, WR-75G, H-BEND ELBOW
13 1
RF/CG-75-40-N RF CROSSGUIDE, WR-75G, 40DB, N FEMALE, GROOVED
14 1
RF/TERM75/350W RF TERMINATION, LOAD, 350 WATT, WR-75G
15 1
FP-0020877 WAVEGUIDE, WR-75, SWITCH TO MAGIC TEE
16 1
FP-0020878 WAVEGUIDE, WR-75, SWITCH TO SWITCH
17 2
FP-0020876 WAVEGUIDE, WR-75, FLEX, E-BEND ELBOW
18 20
HW/6-FLT-ROD #6 WASHER, FLAT, SS
19 48
HW/6-FLT #6 WASHER, FLAT, SS
20 60
HW/6-SPLIT #6 WASHER, SPLIT LOCK, SS
21 28
HW/6-32X1/2SHCS #6-32 X 1/2 SOCKET HEAD CAP SCREW, SS
22 24
HW/6-32X5/8SHCS #6-32 X 5/8 SOCKET HEAD CAP SCREW, SS
23 8
HW/6-32X3/4SHCS #6-32 X 3/4 SOCKET HEAD CAP SCREW, SS
24 8
HW/6-32HEXNUT #6-32 HEX NUT, SS
25 8 HW/8-FLT #8 WASHER, FLAT, SS
26 8 HW/8-SPLIT #8 WASHER, SPLIT LOCK, SS
27 8 HW/8-32X3/8SHCS #8-32 X 3/8 SOCKET HEAD CAP SCREW, SS
28 15 GA/GSKTWR75HALF GASKET, WR-75, HALF THICKNESS, CONDUCTIVE
