PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–12
A.3.1 PCB-4000 X-Band Unit (PL/11285-1) Assemblies
A.3.1.1 X-Band 1:1 Combined Assembly Kit – HPOD (KT/11344-01)
Table A-6. Kit KT/11344-1 BOM
Kit KT/11344-1 (see Figure A-5)
Item
No.
QTY CEFD Part No. Description
3 1 FP/WG11306-1 Waveguide, 90 Degrees Bend with Coupler
4 4 FP/WG11307-1 Waveguide, Transition CPRG-112 to CPRG-137
5 3 SW/WG-HAGS Switch, WR112G, +24V
6 1 RF/ADAP-112-N RF, Magic Tee, Coupler, 7.9 – 8.4 GHz
7 2 FP/WG11300-1 Waveguide, 90 Degrees E Bend CPRG-112
8 3 FP/WG11301-1 Waveguide, 90 Degrees CPRG –112
9 2 FP/WG11308-1 Waveguide, 90 Degrees, H Bend, CPRG-112
10 1 FP/WG11310-1 Waveguide, Combiner, CPRG-112
11 1 RF/X-TERM850W PNQ, RF, Termination. Load 850W
13 15 GA/CPR112-R-F-C Gasket, Round, Full-Thickness
14 1 PL/11285-1 Top Assembly, Combiner Box
15 1 FP/WG1309-1 Waveguide, E Bend SW-to-SW, CPRG-112
20 A/R HW/8-32HEXNUT Nut, Hex, SS
21 A/R HW/8-FLT Washer, Flat, SS
22 A/R HW/8-SPLIT Washer, Lock, Split, SS
23 A/R HW/8-32X1/2SHCS Screw, Socket Head Cap
24 A/R HW/8-32X7/8SHCS Screw, Socket Head Cap
25 A/R HW/SEM6 32X3/8PH Screw, Phil Pan Head
31 1 RF/ADAP-112-N Adapter, RF, CPRG112 to “N”
32 1 RF/CG-112/137INN Cross guide Coupler, 40 dB
50 1 FP/BR11311-1 Mounting Bracket, Switch and Load
51 1 FP/BR11670-1 Bracket, LNA’s 1:1 and Combiner Sys
53 1 FP/BR11375-1 Bracket, Load, XSAT
54 4 RF/N-TERM50M1 50 Ω, 1W DC-8GHz
Note: A/R = As Required
