PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–10
A.3 PCB-4000 1+1 Phase Combiner Box Assemblies
The PCB‐4000 1+1 Phase Combiner standalone unit is available in an X‐Band, C‐Band, or Ku‐Band version. The PCCB may be available as a
top assembly line item or as a kit subassembly item (Figure A‐4).
For example, the standalone PL/11285‐1 X‐Band unit is provided as part of the top‐level KT/11344‐1 X‐Band system assembly kit. It is
also provided as a subassembly item in a box and bracket kit which is, in turn, a line item provided in the top‐level KT‐0000055 C‐Band
or KT‐0020623 Ku‐Band system assembly kits.
Table A-5. PCB-4000 1+1 Phase Combiner Box Kit BOM
Item
No.
Box and Bracket Kit / QTY
CEFD Part No. Description
KT-0000056 KT-0020622
1
N/A N/A PL/11285-1 1+1 Phase Combiner Box, X-Band
1 – PL-0000030 1+1 Phase Combiner Box, C-Band
– 1 PL-0021051 1+1 Phase Combiner Box, Ku-Band
2 1 1 FP-0020874 Bracket, Mounting, Phase Combiner Box
3 4 4 HW/10-FLT Washer, Flat, 3/8, SS
4 4 4 HW/10-SPLIT Washer, Lock, Split, 3/8, SS
5 4 4 HW10-32x1/2SH Bolt, Socket Head, SS
6 2 2 HW-0000070 Screw, Hex, Serrated Flange Head, SS
7 2 2 HW3/8SPRINGNUT Spring Nut, 3/8-16, Short Spring, SS (P3300)
