PCB-4000 1+1 Phase Combiner Revision 2
Serial Remote Control MN/PCB4000.IOM
5–8
Parameter
Type
Command
(Instruction
Code and
qualifier)
Command
Valid for
PCB or
SSPA
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes – i.e.,
ASCII codes between 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
qualifier)
Query Valid
for PCB or
SSPA
Response to
Query
(Target to
Controller)
RF Power
Amplifier State AMP= PCB 1 byte,
value of 0, 1
Command or Query.
Turns ON or OFF the SSPAs in the form AMP=x, where:
0 = Off
1 = On AMP=
AMP?
AMP* AMP? ALL AMP=x
(see Description
of Arguments for
details)
Attenuation
Offset AOF= PCB 7 bytes,
alphanumeric
Command or Query.;
Sets attenuation offset for specified SSPA
Command: AOF=x,yy.yy where:
x=0 or 1 (SSPA number)
yy.yy=Attenuation offset
Query: AOF?
Example: AOF=1,01.50
Note: AOF command will not take values greater than 6 dB)
AOF=
AOF?
AOF* AOF? PCB AOF=x,yy.yy
(see Description
of Arguments for
details)
Attenuation ATT= PCB 5 bytes,
numerical
Command or Query.
Valid attenuation level, in dB, at 0.25-dB step size as factory
default.
Example: ATT=12.25
Note: The attenuation range is limited to a maximum of 24 dB. ATT=
ATT?
ATT* ATT? ALL ATT=xx.xx
(see Description
of Arguments for
details)
AUX Input
Enable AUX= N/A 1 byte,
value of 0, 1
Query only.
Enables AUX input for SSPA mute
<0001V1/AUX?
Where: x is 0 (AUX Mute disabled)
1 (AUX Mute enabled) AUX=
AUX?
AUX* AUX? SSPA AUX=x
(see Description
of Arguments for
details)
Bypass SSPA BYP= PCB 1 byte
value of 0, 1 or
2
Command or Query.
Command: BYP=a, where:
a = 0 (No SSPA is bypassed)
1 (SSPA #1 is bypassed)
2 (SSPA #2 is bypassed)
• Command bypasses the SSPA specified by argument.
• Command works only in RED=0 mode.
Query: BYP?
• Query returns the number of the SSPA that is currently
bypassed or offline.
• Query works in any RED mode.
BYP=
BYP?
BYP* (received ok
but in the wrong
RED mode)
BYP? PCB BYP=a
(see Description
of Arguments for
details)
Clear All
Stored Alarms CAA= ALL None Command only.
Instructs the slave to clear all Stored Events.
This command takes no arguments.
CAA=
N/A
N/A N/A
