PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–20
A.3.3 PCB-4000 Ku-Band Unit (PL-0021051) Assemblies
A.3.3.1 Ku-Band 1+1 Phase Combined System – HPOD (KT-0020621)
Table A-10. Kit KT-0020621 BOM
Kit KT-0020621 (see Figure A-9)
Item No. QTY CEFD Part No. Description
1 1 KT-0000017 1:2 Unistrut Mounting Kit
2 1 KT-0020623 Ku-Band 1:1 HPOD Waveguide and Switch Kit
3 1 KT-0020622 Ku-Band Phase Combiner Box and Bracket Kit
4 2 KT/12300-1 HPOD Mounting Bracket Kit
N/A 2 CA/RF11872-1* Cable Assembly, Ku-Band RF IN
N/A 2 CA/WR11966-1* Cable Assembly, SSPA to Combiner Box
N/A 1 CA/WR12013-1* Cable Assembly, Switches, Combined System
N/A A/R HW/TW14.5HDBLK Cable Ties
Notes:
1. A/R = As Required
2. *See Chapter 3. INSTALLATION, STARTUP, and TROUBLESHOOTING PROCEDURESfor information on making cable connections
in a 1+1 Phase Combiner System.
