PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–14
A.3.1.2 X-Band 1:1 Waveguide and Switch Redundant Assembly Kit – ODPA (KT/11387-1)
Table A-7. Kit KT/11387-1 BOM
Kit KT/11387-1 (see Figure A-6)
Item No. QTY CEFD Part No. Description
3 1 RF/CG-112/137INN Cross guide Coupler, 40 dB, Type N Connector, 137-112
4 1 FP/WG11671-1 Waveguide, 1:1 Filter to TX
5 2 SW/WG-HAGS
Switch, WR112G, +24V, Sealed, Standard Thread, Cold Temperature
Rating
7 2 FP/WG11305-1 Waveguide, 90 Degree H-Bend Transition
8 2 FP/WG11301-1 Waveguide, 90 Degree, CPRG-112
9 3 FP/WG11308-1 Waveguide, 90 Degree, H-Bend, CPRG-112
11 1 RF/X-TERM850W Termination, Load, 850 Watt, CPRG112, with Cross guide Coupler, 40 dB
13 14 GA/CPR112-R-F-C Gasket, Round, CPR112, Full Thickness,
20 A/R HW/8-32HEXNUT Nut, Hex 8-32
21 A/R HW/8-FLT Washer, Flat SS
22 A/R HW/8-SPLIT Washer, Split SS
23 A/R HW/8-32X1/2SHCS Screw, Socket Cap
24 A/R HW/8-32X7/8SHCS Screw, Socket Head Cap, SS
25 A/R HW/SEM632X3/8PH Screw, Square Cone Pan Head Phillips SS
31 1 RF/ADAP-112-N Adapter, CPRG112 to "N"
32 1 RF/CG-112/137INN Coupler, Cross guide 40 dB N Type Connector
55 4 RF/N-TERM50M1 RF, 50 Ω 1Watt, DC-8 GHz, Type N Male
Note: A/R = As Required
