PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–4
A.2 Common Kit Subassemblies
A.2.1 Universal Pole Mounting Kit (PL/12319-1)
Table A-2. Kit PL/12319-1 BOM
PL/12319-1 Universal Pole Mounting Kit (as per Figure A-1 on next page)
Item
No.
QTY CEFD Part No. Description
1 N/A (FP-0000134) Unistrut, Dual Channel (SHOWN FOR CLARITY ONLY, P/O CEFD KT-0000017 MOUNTING KIT)
2 1 FP/BR0072 Bracket, Strap Tensioner
3 1 FP/BR0070 Bracket, Strap Termination
4 1 FP/BR0071 Bracket, 1-1/4 Strap (TRIM TO REQUIRED LENGTH)
5 1 FP/BR0069 Bracket, Strap, Fixed
6 2 HW/M8X1.25X25HEXSS Bolt, Hex head, M8X1.25X25, SS
7 7 HW/M8FLATSS Washer, Flat, M8, SS, METRIC
8 7 HW/M8LOCKSS Washer, Split Lock, M8, SS, METRIC
9 2 HW/M8SPRINGNUT Spring Nut, M8X1.25
10 5 HW/M8X1.25MMHEXNUTSS Nut, Hex M8X1.25X16MM, SS
11 2 HW/PIPEBLOCK Pipe Block
