PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–16
A.3.2 PCB-4000 C-Band Unit (PL-0000330) Assemblies
A.3.2.1 C-Band 1+1 Phase Combined Top Assembly Kit – HPOD (KT-0000055)
Table A-8. Kit KT-0000055 BOM
Kit KT-0000055 (see Figure A-7)
Item No. QTY CEFD Part No. Description
1 1 KT-0000017 1:2 Unistrut Mounting Kit
2 2 KT/12300-1 HPOD Mounting Bracket Kit
3 1 KT-0000056 C-Band Phase Combiner Box and Bracket Kit
4 1 KT-0000054 C-Band 1:1 HPOD Waveguide and Switch Kit
N/A 2 CA/RF11872-1* Cable Assembly, Ku-Band RF IN
N/A 2 CA/WR11966-1* Cable Assembly, SSPA to Combiner Box
N/A 1 CA/WR12013-1* Cable Assembly, Switches, Combined System
N/A A/R HW/TW14.5HDBLK Cable Ties
Notes:
1. A/R = As Required
2. *See Chapter 3. INSTALLATION, STARTUP, and TROUBLESHOOTING PROCEDURESfor information on making cable connections
in a 1+1 Phase Combiner System.
