PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–18
A.3.2.2 C-Band 1+1 Phase Combined Waveguide and Switch Kit – HPOD (KT-0000054)
Table A-9. Kit KT-0000054 BOM
Kit KT-0000054 (see Figure A-8)
Item No. QTY CEFD Part No. Description
1 1 FP-0000414 MOUNTING BRACKET, DUAL VERTICAL SWITCHES, CPR-137
2 4 HW/3/8SPRINGNUT SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
3 4 HW/3/8-FLT 3/8 FLAT WASHER, SS
4 4 HW/3/8-SPLIT 3/8 SPLIT LOCK WASHER SS
5 4 HW/3/8-16X1BLT 3/8 - 16 HEX HEAD BOLT, 1.0 LONG, SS
6 1 FP-0000416 SUPPORT BRACKET, CPR-137 TERMINATION
7 2 HW/1/4-FLT 1/4 FLAT WASHER
8 2 HW/1/4-SPLIT 1/4 SPLIT WASHER
9 2 HW/1/4-20X5/8SHCS SCREW, 1/4-20 X 5/8 SHCS, SCREW, 1/4-20 X 5/8 SHCS, SS
10 2 SW/WGS28V-137S SW WAVEGUIDE, CPR137, +28V SEALED
11 136 HW/10-FLT #10 FLAT WASHER SS
12 128 HW/10-SPLIT #10 SPLIT LOCK WASHER SS
13 64 HW/10-32X1/2SH #10-32X1/2 SOCKET HEAD CAP SCREW, SS
14 9 GA/CPR-137-R-H-C GASKET, D SHAPE, CPR-137, HALF THICKNESS, CONDUCTIVE
15 1 HW-0000131 RF MAGIC TEE, COUPLER, 5.85-6.425 GHz, WR-137G, C-BAND, 4 WAY
16 56 HW/10-32X5/8SHC #10-32 X 5/8 SOCKET HEAD CAP SCREW, SS
17 3 FP-0000410 WAVEGUIDE, CPRG-137, H-BEND ELBOW
18 9 GA/CPR137-R-F-C GASKET, ROUND, CPR137, FULL THICKNESS, CONDUCTIVE
19 1 RF/CG-137-40-N RF CROSSGUIDE, WR137, 40DB, N FEMALE, GROOVED
20 8 HW/10-32X3/4SH #10-32X3/4 SOCKET HEAD CAP SCREW, SS
21 8 HW/10-32HEXNUT #10-32 HEX NUT, SS
22 1 RF/C-TERM1000W RF TERMINATION, LOAD, 1000 WATT, CPRG-137
23 1 FP-0000411 WAVEGUIDE, CPRG-137, SWITCH TO MAGIC TEE
24 1 FP-0000408 WAVEGUIDE, CPRG-137, SWITCH TO SWITCH
25 2 FP-0000409 WAVEGUIDE, CPRG-137, E-BEND ELBOW
