Operation RCF6001 Satellite Terminal
Page 3-4 TM082 Rev. 1.0
C-Band Block Upconverter Specifications
Electrical Performance Parameters
Output frequency range 5.85 – 6.425 GHz
Input frequency range 950 – 1525 MHz
Input level range -5 to –55 dBm (-20 for P1dB)
Reference signal frequency 10 MHz
Reference signal level -3 to +10 dBm
Power levels Available up to 40 watts
Ku-Band Block Upconverter Specifications
Electrical Performance Parameters
Output frequency range 14.0 – 14.4 GHz
13.75 – 14.25 GHz (option)
Input frequency range 950 – 1525 MHz
Input level range -5 to –55 dBm (-20 for P1dB)
Reference signal frequency 10 MHz
Reference signal level -3 to +10 dBm
Power levels Available up to 25 watts
(The following specifications apply to both C- and Ku-Band Bucs)
Intermodulation IM
3
> -30 dBc
(Two tone signal with 5 MHz distance and a summary output power
of 6 dB below rated power, 6 dB back off)
Gain stability
± 0.5 dB/day at constant temperature
Gain variation (flatness) ± 2 dB over 500 MHz
(over freq. and temp.) ± 1 dB over any 80 MHz band
Group delay < 10 ns over any 80 MHz band
Carriers transmit interrupt > 50 dB
Local oscillator phase noise < 2.8 o RMS double sideband
Spurious < -20 dBm (in-band)
Noise figure < 20 dB
DC input 42 to 60 Vdc (nominal 48V)
(24 Vdc optional)
