Maintenance RCF6001 Satellite Terminal
Page 4-12 TM082 - Rev. 1.0
NOTE: The frequencies of the Block Upconverter (BUC) and LNB must be entered first under the
‘System/General’ menu. The LB/ST will then calculate the Mod and Demod IF/RF frequencies.
Tx RF
This Frequency is precalculated by the LB/ST after the operator has
entered the frequencies of the BUC and LNB under the System/General
menu.
Tx IF
Enter in 1 MHz steps from 950-1525 MHz
Spectrum Inv
Inverts the direction of rotation for PSK modulation in demod.
Normal meets the IESS specification
Demodulation
Sets Demodulation type QPSK, BPSK, OQPSK
Swp Bound
Sets acquisition range for the demodulator
Input Limit
Demod Data
Data Rate
Sets Data Rate in BPS Steps. Use arrows or Keypad
Conv Dec
Selects Rx code rate and type
Diff Decode
Enables or disables differential decoder
Dscrmbl Sel
Selects descrambler type
Dscrmbl Ctrl
Enables or disables descrambler operation
Data Invert
Sets data polarity to Normal, Inverted, or Auto.
Reed-Solomon
Enable/Disable the Reed-Solomon Decoder
DMDRS Codes
Displays the currently used n, k Reed-Solomon Codes. In
Closed Net Mode, custom RS codes may be selected.
DMDRS Depth
Displays the currently used Reed-Solomon deinterleaver depth.
In Closed Net Mode, Depth = 8 or 4 may be selected.
Interface
General
EXT Clk Freq
Selects Frequency of External Clock.
Freq Ref Src
Selects Internal, External, or High Stability
Ext Ref Freq
Sets the External Reference Frequency
Intf Type
Selects Interface type, V.35/422/232
Tx Setup
Tx Ckt ID
Provides entry of Tx circuit Identifier
Circuits can be given up to an 11 character alphanumeric identity
Tx Clock
SCT (Int)
