ODU Installation RCF6001 Satellite Terminal
Page 5-10 TM082 - Rev. 1.0
Mounting the Typical 8-Watt / 16-Watt Outdoor Unit (BUC)
The following diagram and instructions pertain to mounting an 8-Watt or 16-Watt
ODU (BUC) to an antenna using a Radyne ComStream supplied mounting plate
and hardware kits.
The 8-Watt or 16-Watt Outdoor Unit is pre-assembled as shown in Figure 5-2. The
User antenna type and design determine the mounting location of this assembly.
The flexible waveguide is not provided with the mounting kit.
Figure 5-2. 8-Watt / 16-Watt Mounting
Insert Figure 5-2.
Table 5-4 Offset Mounting Kit (3110-0002)
Item Part # Description Qty
1 MS9068-022 “O” Ring Parker 1
2 2400-3038-610 SCRPNHD 6-32x5/5 LG 8
3 2400-3044-136 Washer, Medlock NO. 6 8
4 36015 U-Bolt 2
5 2400-3044-141 Washer, Medlock 3/8 4
6 2400-3045-814 Washer, FL 3/8 OD. 81 4
7 2400-3047-010 Nut, Plain Hex 3/8-16 4
Step 20. Important: Make sure that the “O” Ring is installed and that the waveguide flange is
properly sealed to prevent moisture from entering the waveguide.
Step 2. First secure the bottom section of the ODU mounting assembly by placing
the ODU (BUC) mounting assembly onto the diagonal support member
and secure using (1) U-Bolt and noted hardware.
Step 3. Secure the top section of the ODU (BUC) mounting assembly onto the
cross member (support pole/pipe) and secure using (1) U-Bolt and noted
hardware.
Step 4. If applicable, attach flexible waveguide between the ODU (BUC) and feed
assembly using the hardware noted.
Interface Connections for the 8-Watt / 16-Watt ODU (BUC)
The following describes the various “USER” connections located on the 8-Watt and 16-
Watt ODU (BUC).
Step 21. This section provides information pertaining to the SSPA interface connections. Refer
to Section 5.4 for ODU (BUC) Interface Connections.
