RCF6001 Satellite Terminal ODU Installation
TM082 - Rev. 1.0 Page 5-19
Table 4-8C-Band ODU ( BUC ) / Feed Parts List
(3120-0004)
Item # Part # Description Qty
1 3120-1032 MTG PLATE, HORN SUPPORT 1
2 3110-1042 BRACKET-OFFSET, BUC TAIL MOUNT 1
3 0200-935 PRODELIN SUPPORT KIT (See Below) 1
4 2400-3034-1409 SCRHEXHD 1/4-20X1.0” 22
6 2400-3044-139 WASHER, MEDLOCK, 1/4 24
7 2400-3045-810 WASHER, FLAT 1/4 OD.62 42
8 2400-3047-008 NUT,PLAIN HEX 1/4-20 22
11 22117P2 GASKET, WR229 1
13 3120-0001 MISC. KIT (See Below) 1
14* 2400-3039-1408 SCRSKTHD, 1/4-20X7/8LG 2
15* 3120-5610 BRACE, SUPPORT 2
(3120-0001)
101 16267P2 GASKET 1
102 2400-3039-1008 SCRSKTHD 10-32X5/8LG 8
103 2400-3044-138 WASHER, MEDLOCK #10 8
104 2400-3043-3808 SCRHXHD 3/8-16X1LG 1
105 2400-3044-141 WASHER, MEDLOCK 3/8 1
106 2400-3045-814 WASHER, FLAT 3/8 OD.81 1
(0200-935)
201 0490-588 BRACKET ASSY, MTG 1
202 0490-667 SUPPORT BRACE 1
203 0156-058 PLATE, MTG 1
204 2400-3043-1416 SCRHEXHD 1/4-20X2LG 3
205 2400-3043-1418 SCRHEXHD 1/4-20X2.5LG 1
206 2400-3044-139 WASHER, MEDLOCK, 1/4 6
207 2400-3045-811 WASHER, FLAT 1/4 OD .73 12
208 2400-3047-008 NUT,PLAIN HEX 1/4-20 6
209 2400-3043-1408 SCRHXHD, 1/4-20X7/8LG 2
* May not be supplied with all kits.
