RCF6001 Satellite Terminal ODU Installation
TM082 - Rev. 1.0 Page 5-5
Mounting the Typical 1, 2 or 4 Watt Outdoor Unit
The following diagram and instructions pertain to mounting a 3100 Series ODU and
LNB to an antenna using a Radyne ComStream supplied mounting plate. The
mounting plate along with the miscellaneous hardware kits are not provided with the
system unless specified or requested per the USER purchase order.
ODU Mounting Kits
BUC Mounting Kit Description (3110-0003)
The BUC mounting kit provides the mechanical support hardware for mounting the
BUC to a Prodelin offset feed dish with aperture size of 1.8m, 2.4m and 3.8m.
Step 9. Refer to Figure 5-1 and Table 5-3.
BUC Miscellaneous Hardware Kit Description (3110-0001)
The BUC miscellaneous hardware kit contains the hardware and "O" ring for
connecting a BUC to a feed system. This hardware is separate from the mounting kit
described above since this hardware is required for all types of antenna systems.
Attaching the ODU (BUC) / Feed Assembly
This document describes the steps required to assemble and integrate the Radyne
ComStream Ku-Band BUC to a Prodelin antenna system. This document does not
describe the installation instructions for the antenna system. Please refer to antenna
manufacturer’s manual. The following steps outline the procedure to attach the
Radyne ComStream BUC and LNB to the antenna feed support.
