ODU Installation RCF6001 Satellite Terminal
Page 5-26 TM082 - Rev. 1.0
2. BUC / SSPA Interface Port
Function: Provides the serial interface for communications between the BUC and SSPA.
When configured as a 10-Watt system the 48VDC source voltage for the SSPA
is routed through this port. When configured as a 20-Watt system the AMP
Controller provides the 48VDC source voltage. This cable is provided with the
system.
3. WR137 Waveguide Flange, Grooved
Function: SSPA RF Output port to antenna feed
4. Female Type “N” Connector
Function: ODU (BUC) Interface for L-Band Input connection from IDU
Step 56. Receives the modulated L-Band (950 - 1525 MHz) signal from IDU.
Step 57. Interface for a 10 MHz reference, 48 VDC power, and an FSK monitor and control (M&C) link.
Step 58. Refer to Section 4.2, IFL Cable Installation Guidelines.
Step 59. Refer to Section 4.2.1, General Cable Installation Considerations prior to installing the cable.
Step 60. Refer to Table 4-2, IDU to ODU Interface Cable Requirements.
Installation Verification
Verify that the following parameters have been adhered to while installing the unit.
10) All equipment located around or mounted directly on the antenna are bonded together and
grounded to a proper earth ground.
11) The unit is located within or in a manner that allows ease of service.
12) The unit is properly secured in place.
13) All outdoor cable connections are properly seated, secured and waterproofed. A connector
strain relief has been added to each cable end.
