RCF6001 Satellite Terminal Maintenance
TM082 - Rev. 1.0 Page 4-15
Minor Tx
Tx Activity
TerrClk Mask
Indicates no terrestrial clock activity.
IntClk Mask
Indicates no SCT clock activity.
BNCClk Mask
Indicates no BNC clock activity
TxSatCk Mask
Indicates no Tx Sat clock activity
Tx Data Mask
Indicates no Tx data activity.
TerrAIS Mask
Indicates that AIS has been detected in the Tx data
stream.
Minor Rx
BufUFLw Mask
Indicates that a Doppler buffer underflow has occurred.
BufOFLw Mask
Indicates that a Doppler buffer overflow has occurred.
Buf <10% Mask
Indicates that the Doppler buffer is about to underflow.
Buf >90% Mask
Indicates that the Doppler buffer is about to overflow.
VitLock Mask
Indicates that the Viterbi decoder is not locked.
SequLock
Indicates that the Sequential decoder is not locked.
Rx Activity
Buf Clk Mask
Indicates that the selected buffer clock source is not
active.
Ext BNC Mask
Rx Sat Mask
Indicates that the Rx Sat buffer clock source is not
active.
ExtRef Mask
SatAIS Mask
Indicates that AIS has been detected in the Rx data
stream.
Rx RS Faults
Dec Lock
Indicates status of the Reed-Solomon Decoder
Lock
Dintlvr
Indicates status of the Reed-Solomon de-
interleaver word fault
UnCWord
Indicates status of the Reed-Solomon uncoded
word fault
Common
-12 Power
Indicates power supply voltage out of range.
+12 Power
Indicates power supply voltage out of range.
