Maintenance RCF6001 Satellite Terminal
Page 4-14 TM082 - Rev. 1.0
Sets the time base for the channel error rate measurement, used to
estimate Eb/No. This number is ‘N’ in the following equation: B=10
N
;
where: ‘B’ is the number of data bits in the averaging period.
Alarms
Modem Alarms
Active Alrms
Major Tx
TxuProc Mask
Tx Processor fault
Indicates a HW failure within the modem.
TxPower Mask
Indicates that the Modem Tx output power is within allowed
tolerance. A solid indication indicates a HW or programming
failure within the modem.
TxOSClk Mask
Indicates that the TX Oversample clock PLL is not locked. This
alarm will flash on during certain modem parameter changes. A
solid indication indicates a HW or programming failure within the
modem.
CompClk Mask
Indicates that Tx composite clock PLL is not locked.
This alarm will flash on during certain modem parameter
changes. A solid indication indicates a HW or programming
failure within the modem.
TxSynth Mask
Indicates that Tx IF synthesizer is not locked.
This alarm will flash on during certain modem parameter
changes.A solid indication indicates a HW or programming
failure within the modem.
FPGACfg Mask
REF PLL MASK
Pass/No
TxForce
Pass/No
Major Rx
RxuProc Mask
Rx Processor fault
Indicates a hardware failure within the modem.
SigLoss Mask
Indicates that the demod is unable to lock to a signal.
IF Synth Mask
Indicates the Rx IF synthesizer is not locked.
This alarm will flash ON during certain modem parameter
changes. A solid indication indicates a HW or programming
failure within the modem.
BuffPll Mask
RxLevel Mask
RxForce Mask
