ODU Installation RCF6001 Satellite Terminal
Page 5-12 TM082 - Rev. 1.0
Function: Provides the serial interface for communications between the BUC and
SSPA. When configured as an 8-Watt system the 48 Vdc source
voltage for the SSPA is routed through this port. When configured as a
16-Watt system the AMP Controller provides the 48 Vdc source
voltage.
3. WR75 Waveguide Flange, Grooved
Function: SSPA RF Output port to antenna feed
4. Female Type “N” Connector
Function: ODU (BUC) Interface for L-Band Input connection from IDU
Step 26. Receives the modulated L-Band (950 - 1450 MHz) signal from IDU.
Step 27. Interface for a 10 MHz reference, 48 VDC power, and an FSK monitor and control
(M&C) link.
Step 28. Refer to Section 5.2, IFL Cable Installation Guidelines.
Step 29. Refer to Section 5.2.1, General Cable Installation Considerations prior to installing the
cable.
Step 30. Refer to Table 5-2, IDU to ODU Interface Cable Requirements.
Installation Verification
Verify that the following parameters have been adhered to while installing the unit.
6) All equipment located around or mounted directly on the antenna are bonded
together and grounded to a proper earth ground.
7) The unit is located in a manner that allows ease of service.
8) The unit is properly secured in place.
9) All outdoor cable connections are properly seated, secured and waterproofed. A
connector strain relief has been added to each cable end.
