ODU Installation RCF6001 Satellite Terminal
Page 5-16 TM082 - Rev. 1.0
Prodelin Antenna BUC Mounting Kit (C-band 3120-0004)
The BUC mounting kit provides the mechanical support hardware for mounting the C-band BUC
to a Prodelin offset feed dish with aperture size of 1.8m, 2.4m and 3.8m. This top assembly kit
contains the 3120-0001 BUC Misc. Hardware Kit and the 0200-935 Antenna Support Kit.
Step 37. Refer to Figure 4-1 and Table 4-3.
BUC Misc. Hardware Kit Description (C-band 3120-0001)
The BUC miscellaneous hardware kit contains the hardware and gasket for connecting a BUC to
a feed system.
Antenna Support Kit Description (0200-935)
The antenna support hardware kit contains the hardware and bracket assemblies required to
properly support the weight of the BUC and feed assembly.
Attaching the ODU (BUC) / Feed Assembly
This installation procedure describes the steps required to install the Radyne ComStream C-
Band BUC to a Prodelin antenna system. This manual does not describe the installation
instructions for the antenna system. Please refer to antenna manufacturers manual. The steps
outlined below are used to attach the Radyne ComStream BUC and LNB to the feed assembly
and secure to the antenna feed support.
