RCF6001 Satellite Terminal ODU Installation
TM082 - Rev. 1.0 Page 5-7
Step 10. Radyne ComStream does not provide the OMT assembly. Radyne ComStream can
provide the transmit reject filter as an option.
Table 5-3 ODU ( BUC ) / Feed Parts List
Item # Part # Description Qty
1 3110-1032 MTG PLATE, HORN SUPPORT 1
2 3110-1033 MTG PLATE, BUC REAR SUPPORT 1
3 3110-1034 MOUNTING PLATE 1
4 2400-3043-5608 SCRHEXHD 5/16-18 X 1.0” 2
5 2400-3044-140 WASHER, LOCK 5/16 2
6 2400-3045-813 WASHER, FLAT 5/16 OD .88 4
7 2400-3047-009 HEX NUT 5/16-18 2
8 2400-3040-1407 SCR82FL ¼-20 X ¾ 4
9 2400-3043-3808 SCRHEXHD 3/8-16 X 1.25” 1
10 2400-3044-141 WASHER, LOCK 3/8 1
11 2400-3045-814 WASHER, FLAT 3/8 OD .81 1
12 MS9068-025 “O” -RING 2
13 2400-3038-610 SCRPNHD 6-32X5/8 4
14 2400-3044-136 WASHER. LOCK #6 4
15 DIN912-M4X14MM SCREW SOC HD 4
16 DIN127-M4 WASHER, LOCK M4 4
Step 11. Items 1-8, 12, 15-16 are part of the BUC Mounting Kit Part Number 3110-0003.
Step 12. Items 9-11 and 13-14 are part of the BUC Miscellaneous Hardware Kit Part Number
3110-0001.
Step 12. Place the feed / BUC assembly onto the antenna feed support and secure
using two 5/16-18x1 hex screws (item 4), four 5/16 flat washers (item 6),
two 5/16 lock washers (item 5) and two 5/16-18 hex nuts (item 7). Tighten
securely.
Step 13. Insert one “O” Ring (item 12) into the grooved flange of the transmit reject
filter. Attach transmit reject filter and LNB to the receive port of the OMT
using four each lock washers (item 16) and socket screws (item 15).
Step 14. Adjust the feed / BUC / LNB assembly to set the desired polarization.
Tighten the horn strap and BUC rear mount bolt securely.
Step 15. The RF head assembly is complete. Refer to antenna system and VSAT
system operation manuals for antenna alignment and system operation.
