RCF6001 Satellite Terminal Operation
TM082 Rev. 1.0 Page 3-3
Alarms
Summary Alarms: Two separate form-C contacts
available at the rear panel. Each
provides a summary alarm of fault conditions.
Front Panel LED Indicators
Unit: Power
Alarm
Event
Remote
Demodulator: Signal Lock
Major Alarm
Minor Alarm
Test Mode
Modulator: Transmit On
Major Alarm
Minor Alarm
Test Mode
Monitor and Control
All operating parameters can be monitored and controlled via the front panel display/keypad or the RS485 or
RS232 serial control channel in either terminal or command modes. The following modem parameters may be
controlled and/or monitored:
Transmit and Receive Frequencies
Transmit and Receive Offsets
Modulator Power Level
Modulator On/Off
Modulator/Demodulator Modulation (BPSK, QPSK or OQPSK)
Modulator/Demodulator Data Rates (1 bps steps)
Modulator/Demodulator Code Rates (1/2, 3/4, 7/8)
Modulator/Demodulator Differential Decoders (On/Off)
Modulator/Demodulator Scrambler (On/Off)
Modulator/Demodulator Data (inverted or non-inverted)
Modulator/Demodulator Clock Source and Phase
Demodulator FIFO Size, Delay and Status
Demodulator Eb/No
Demodulator Low Eb/No
Demodulator Measure BER and Estimated BER
Modulator/Demodulator Alarms
Options
Concatenated Codec: A Reed-Solomon codec is available.
Asynchronous Channel: Asynchronous overhead
channel for remote control and
order-wire applications.
Viterbi and Sequential Coding
Environmental
Prime Power: 100-240 Vac, 50-60 Hz, 1.0 A
(IEC 3-pin Power Connector with Switch)
Outdoor Unit Power: 150 Watts, 100 - 240 Vac, Autoranging
Operating Temp.:
0 to 50 o C, 95% humidity, non- condensing
Storage Temp.: -20 to 70 o C, 99% humidity, non-condensing
Physical
Chassis size: 19 x 17 x 3.5 inches
(48.26 x 43.2 x 4.45 cm)
Weight: 16 pounds (7.2 Kg)
Shipping Weight: 20 pounds (9.0 Kg)
