CDM-625A Advanced Satellite Modem MN-CDM625A
Appendix U Revision 3
U–3
ftp: XXXX bytes received in X.XXSeconds XXXXXXX.XXKbytes/sec.
ftp>
• Type "bye" without quotes at the Command-line ftp> prompt to terminate the FTP
session, and then close the Command-line window.
U.2.2 Use the Modem Configuration File to Configure a Target Modem
1) OPTIONAL – You may optionally edit the Modem Configuration File to instruct the modem
to save, upon execution of the FTP “put” command (see Step 3), the configuration
parameters of this file to a specified modem configuration slot (as you would by using the
CDM-625A Front Panel SELECT: Store/Ld ►Store screen).
• Make sure that you are in the folder containing the Modem Configuration File
(config_file) created in Sect. U.2.1.
• Use a text editor such as Windows Notepad to open the Modem Configuration File
(config_file).
• Add, as the first line in the configuration file, “SAVE MGC TO SLOT #” without quotes
(where # is modem configuration slot 0 through 9), as per this example…
► SAVE MGC TO SLOT 6
MGC=0070.000…etc.
OGC=010x00xxx…etc.
DNI=100000000…etc.
etc…
This text string is case-sensitive. Be sure to specify an “Available”
configuration slot.
• Save and close the Modem Configuration File. Continue to the next step.
2) Use Command-line to send a “PING” command to confirm proper connection and
communication between the User PC and the CDM-625A Target Modem:
• Open a Command-line window…
For Windows 95 or Windows 98, type “command”.
For any Windows OS versions later than Windows 98, type “cmd” or “command”.
Alternately, from [Start], select All Programs > Accessories > Command Prompt.
