CDM-625A Advanced Satellite Modem MN-CDM625A
Telnet Command Line Interface (CLI) Operation Revision 3
9–87
9.3.10.7 Home > Statistics > QoS
Open the QoS statistics page from the Statistics submenu:
Hot
Key Page / Dialog Window
Option Entry / Description
A QoS Clear Counters Use the ↑↓ arrow keys to select Cancel or Clear
B View Statistics Table See Sect. 9.3.10.7.1
Press a hot key to open the dialog window or view the table. Otherwise, press [ESC] to return to
the Statistics submenu.
9.3.10.7.1 Home > Statistics > QoS > Table View
Open the scrollable QoS statistics table from the nested QoS submenu.
Use the ↑↓ arrow keys to scroll through the available entries. You may also select a header
(e.g., ) and press [ENTER] to view, in a standalone window, a specific set of
statistics as shown in th i s example:
Press [ESC] to return to the Compression page.
