CDM-800 Gateway Router Revision 1
Ethernet-based Remote Product Management MN-CDM800
5–46
o Then, use the top (Save) Select Location dropdown to select 1 through 10.
o Finally, click [Save Configuration] to store the configuration settings.
• To load (recall) a configuration set:
o
First, use the bottom (Load) Select Location dropdown to select 1 through 10.
o Then, click [Load Configuration] to recall the selected configuration settings.
BERT Config
(Where BERT is the acronym for Bit Error Rate Test) Use the drop‐down menus to:
• Configure the Tx BERT State as On or Off.
• Configure the Tx or Rx BERT Pattern as 2^23‐1 (2
23 ‐1) or 2047.
• Set Error Insert(ion) as either Off or 10E‐3.
Click [Submit] to save the BERT settings and execute the test.
Once the Tx BERT is executed, the entire outbound carrier transmits a BERT pattern.
All IP communications are halted during this test.
Note also that the Rx BERT State for the CDM‐840 Remote Router must be enabled
to properly receive and monitor the BERT pattern.
Redundancy
• Current Redundancy State (read‐only) – Status is listed as On Line or Off Line.
• Offline Unit Status (read‐only) – This indicates the status of the offline unit.
If the unit is not connected to a redundancy switch, the status is listed as No_1F1.
Otherwise, its status is listed as On Line or Off Line.
If the unit is part of a 1:1 or 1:N redundant pair of CDM‐800s, and this unit is currently On Line,
click [Force Redundancy Switch] to cause the unit to switch to standby.
