Web Guide / Light Bar Parts List
ITEM PART NO. DESCRIPTION QTY
1 374059 SHAFT, SENSOR GUIDE 4
2 374060 SHAFT, WEB GUIDE ADJUST 1
3 374055 SENSOR GUIDE HOLDER 1
4 374061 WEB GUIDE ADJUST 1
5 374051 BRACKET, WEB GUIDE 2
6 374049 BRACKET, LED MOUNT 1
7 374050 BRACKET, SENSOR MOUNT 1
8 514102 ASSY.MOUNT 1
9 999100 BUSHING, FLANGE,3/16 X 5/16 X 1/8 6
10 554059 SHAFT, THEADED LOWER 1
11 554058 SHAFT, SENSOR ADJUST 1
12 554005 DRIVE, WEB GUIDE ADAPTOR 1
13 554004 BRACKET, WEB GUIDE MOUNT 1
14 374058 GEAR, 36T 1
15 554064A DRIVER, SENSOR ADJUS GEAR 2
16 105023K KNOB, IMPRESSION ADJUST 1
17 551169 SENSOR, LED WIRED 1
18 532015 CLAMP, SENSOR 1
19 371128 TOP&BOTTOM REFLECT SENSOR 1
ITEM PART NO. DESCRIPTION QTY
20 554006 BRACKET, WEB MOUNT, FRONT 1
21 990091 #10-32 X 1/2B.H.C.SCREW 8
22 990424 #4-40 X 3/8 S.H.C. SCREW 1
23 990448 WASHER 1/8 1
24 990090 #10-32 X 3/8 B.H.C.SCREW 4
25 991279 4-40 X 1/8 B.H.C.SCREW 2
26 990016 #6-32 X 3/8 S.H.C.SCREW 1
27 990312 #6 THUMB KNOB 1
28 990262 1/4 SNAP RING 1
29 990007 #4-40 X 1/8 SET SCREW 4
30 990058 #8-32 X 1/4 SET SCREW 1
31 516001 BRACKET, STATIC BRUSH 1
32 989978 #8 STAR WASHER 2
33 355039 STATIC BRUSH 1
34 990066 8-32 X 1/4 BUTTON HEAD CAP SCREW 2
35 990069 #8 HEX NUT 2
36 990119 1/4-20 X 3/8 CAP SCREW 1
37 196028 KNOB, BLACK (GLOSS) 1
