36 • •• • Control Panel Operation
FEATURE SETUP SCREEN
P R E S S E N T E R F O R
F E A T U R E S E T U P
This screen follows the LIFE COUNT\VERSIONS screen.
Pressing ENTER shows the first screen under setup.
Pressing the MODE/Down Arrow key will take the user to the PRINT/CUT
POSITIONS screen.
Pressing the EXIT/Up Arrow key will take the user back to the HOME screen.
C U T T E R I S E N A B L E D
P R E S S E N T E R T O D I S A B L E
OR
C U T T E R I S D I S A B L E D
P R E S S E N T E R T O E N A B L E
This screen is the first screen of SETUP. This screen allows the cutter to be enabled
or disabled. Pressing ENTER will toggle from ENABLED to DISABLED and vice
versa. Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
E M U L A T I O N M O D E : N O N E
N E W E M U L A T I O N M O D E : 6 3 0
This screen follows the CUTTER ENABLE/DISABLE screen. This screen allows
the EMULATION MODE to be changed. Use the keys to move
between NONE, 630, and 650 modes. Pressing ENTER will update the emulation
mode with the selection after new emulation mode. Pressing the MODE/Down
Arrow key will take the user to the next screen. Pressing the EXIT/Up Arrow key
will take the user back to the "HOME" screen.
D E F A U L T T R A N S F E R T Y P E 1
V A L U E : X X X N E W V A L U E : Y Y Y
This screen follows the EMULATION screen IF emulation mode is something other
than none. This screen allows the DEFAULT TRANSFER TYPE to be changed.
This transfer type is used when the printer is in 630 or 650 emulation mode for print
station 1. The 630 and 650 do not send valid 676 transfer types in their PCL code.
This default is used for those formats. Use the keys change the
number value at the cursor position. Pressing ENTER will update the current
position with the selection and move the cursor to the next position. All three
positions must be entered. (I.e. 053 for type 53). After ENTER is pressed on the last
digit the TRANSFER TYPE on the top line will be updated. Pressing the
MODE/Down Arrow key will take the user to the next screen. Pressing the EXIT/Up
Arrow key will take the user back to the "HOME" screen.
D E F A U L T T R A N S F E R T Y P E 2
V A L U E : X X X N E W V A L U E : Y Y Y
This screen follows the DEFAULT TRANSFER TYPE1 screen IF emulation mode is
something other than none. This screen allows the DEFAULT TRANSFER TYPE to
be changed. This transfer type is used when the printer is in 630 or 650 emulation
