Page 33
Users Manual Model 676
Control Panel Operation •
••
• 33
CALIBRATE SENSORS
P R E S S E N T E R T O
C A L I B R A T E S E N S O R S
This screen follows “PRINT HEAD SETUP”.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
H O L E / S L O T I N S E N S O R
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This is the first screen under CALIBRATE SENSORS. Place the stock hole/slot
sense mark under the sensor. Slowly move stock under sensor until NEW VALUE
reads its smallest value then press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
H O L E / S L O T N O T I N S E N S O R
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows HOLE/SLOT IN SENSOR under CALIBRATE SENSORS.
Place stock under the sensor so that it blocks the sensor and when NEW VALUE is at
is largest value press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
T O P R E F L O V E R M A R K
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows HOLE/SLOT NOT IN SENSOR under CALIBRATE
SENSORS. Place stock under the sensor so that the reflective mark is under the
sensor and when NEW VALUE is at is largest value press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
T O P R E F L N O T O V E R M A R K
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows TOP REFL OVER MARK under CALIBRATE SENSORS.
Place stock under the sensor so that the stock is under the sensor but the reflective
mark is not under the sensor and when NEW VALUE is at is smallest value press
‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
