34 • •• • Control Panel Operation
B O T R E F L O V E R M A R K
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows TOP REFL NOT OVER MARK under CALIBRATE
SENSORS. Place stock over the sensor so that the reflective mark is over the sensor
and when NEW VALUE is at is largest value press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
B O T R E F L N O T O V E R M A R K
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows BOT REFL OVER MARK under CALIBRATE SENSORS.
Place stock over the sensor so that the stock is over the sensor but the reflective mark
is not over the sensor and when NEW VALUE is at is smallest value press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
S T A C K E R B L O C K E D
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows BOT REFL NOT OVER MARK under CALIBRATE
SENSORS. Place stock in the stacker jam sensor so that the stock is within the
sensor site path and when NEW VALUE is at is highest value press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
S T A C K E R N O T B L O C K E D
V A L U E : 0 0 0 N E W V A L U E : 0 0 0
This screen follows STACKER BLOCKED under CALIBRATE SENSORS.
Remove any stock from the stacker jam sensor so that no stock is within the sensor
site path and when NEW VALUE is at is lowest value press ‘Enter’.
Pressing the MODE/Down Arrow key will take the user to the next screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
LIFE COUNTS / VERSIONS
P R E S S E N T E R F O R
L I F E C O U N T S / V E R S I O N S
This screen follows the CALIBRATE SENSORS screen.
Pressing ENTER will take the user to the Life Count and Operating system version
number Screens.
Pressing the MODE/Down Arrow key will take the user to the SETUP screen.
Pressing the EXIT/Up Arrow key will take the user back to the "HOME" screen.
