26 • •• • Control Panel Operation
Display Modes
There are four (4) main mode levels that are selected and modified using the
following function keys:
Use the MODE ↓ key to move through the main mode screens shown below:
Pressing the EXIT/Up arrow button will put the user at one of these two screens.
HOME SCREEN
R E A D Y F O R B A T C H E S
6 7 6 / 3 0 0
OR
B A T C H I D Q U A N T I T Y
P C L 0 0 1 1 0
Press the MODE/Down arrow button will cycle the panel through the following main
screens.
PRINTER ADJUSTMENTS
P R E S S E N T E R F O R
P R I N T / C U T P O S I T I O N S
PRINTHEAD ADJUSTMENTS
P R E S S E N T E R F O R
P R I N T H E A D S E T U P
CALIBRATE SENSORS
P R E S S E N T E R F O R
C A L I B R A T I N G S E N S O R S
LIFE COUNTS / VERSIONS
P R E S S E N T E R F O R
L I F E C O U N T S / V E R S I O N S
