• Electrical Trouble Shooting
Cut / Stack
Problem
Probable Cause
Corrective Action
Machine fails to cut labels
(the rotary knife does
not rotate).
1) The cut is disabled in the setup
menu.
1) Enable the knife in the setup menu via the front
panel.
2) Knife cable unconnected.
2) Power off and remove the power cord from the
AC entry. Remove the back cover and inspect
the cable and connector to the knife module.
Refer to the "Electrical System Schematic".
3) Knife jammed causing auto
resetting fuse to trip on the
Thermal Control Board.
3) Remove cause of jam at the knife.
4) Faulty knife motor.
4) Replace the knife motor.
5) Faulty knife motor drive circuit
on the Thermal Control Board.
5) Replace the Thermal Control Board.
The stacker fails to run.
1) The stacker cable is unconnected.
1) Power off and insert the stacker cable in the
stacker port on the Thermal Control Board.
2) Faulty stacker motor.
2) Replace the stacker motor.
3) Stacker jammed causing auto
resetting fuse to trip on the
Thermal Control Board.
3) Remove cause of jam at the stacker.
4) Faulty stacker motor drive circuit
on the Thermal Control Board.
4) Replace the Thermal Control Board.
