Stacker Parts List (Part 2)
Item
Part #
Description
Qty
Item
Part #
Description
Qty
1
184002 Thumb Screw Lock Knob
1
23
990085 10-32 x 1-1/4 Cap Screw
2
2
188008 "T" Nut, Machined Square
2
24
990102 Washer, #10 SAE
2
3
348015 Shaft, Roller Pin
2
25
990006 4-40 x 1/4 Cap Screw
2
4
351161 Stacker Motor Harnessed
1
26
989976 Washer, #6 Star
1
5
358007 Rail, Front Stacker
1
27
990015 6-32 x 1/4 Cap Screw
1
6
358013 Trip Rod
1
28
990038 #6 Hex Nut
1
7
358015 Support, Roller
1
29
990262 Snap Ring, 1/4"
2
8
358017 Spring, Trip Rod
2
30
991007 Pulley, 15T, 1/4 ID, 1/5
1
9
358020 Support, Label Side
1
31
378061 Slide, Stacker Rail
1
10
358033 Bracket, Stacker Support
1
32
990028 6-32 x 3/8 Flat Head Screw
2
11
358094 Roller, Stacker Support Ass’y
2
33
378041 O-Ring (*NS)
19
12
378005 Rail, Rear Stacker
1
34
558006 Bracket, Roller Lock, Front
1
13
378052 Shaft, Tension Roller
1
35
558007 Bracket, Roller Lock, Rear
1
14
378056 Roller, Idler Center
1
36
990056 8-32 x 1/2 Flat Head Screw
2
15
378058 Bracket, Stacker Base
1
37
990272 Washer, #8 Belleville
2
16
378097 Assembly, Stacker Roller
1
38
991157 8-32 E-S Nut
2
17
999014 1/4 x 5/8 FL. Ball Bearing
4
39
144034 Feed Lock Knob
2
18
990313 #10 Thumb Screw Knob
2
40
989979 10-32 x 1 Knurled Cup Point
2
19
990369 1/8" Collar
2
41
558008 Drive, Bearing Support
2
20
990641 6-32 Wing Nut
2
42
990082 10-32 x 5/8 Cap Screw
2
21
990037 Washer, #6 SAE
2
43
999095 3/16 x 5/16 x 3/8 Bushing
2
22
990450 Standoff, 3/8 x 15/16 Round
Spacer
2
(*NS) = Not Shown
