2.5.1 Rack Mount Installation of a Single DLM Series 600W Unit
Follow the procedure below to install a single Sorensen DLM 600W Series power supply
in a rack using the Rack Mount Kit, Sorensen part number DLMRK.
Refer to Figure 2-2.
1. Remove the four (4) rubber feet and mounting hardware from the bottom of the
unit and discard.
2. Remove the four (4) truss head screws (two on each side) from the front side
panels of the unit. (Do not discard.)
3. When rack mounting a unit, it can be mounted on the right or left hand side of the
rack.
4. Install Rack Mount Extruded Ear on the front side of unit using the two (2)
existing truss head screws.
5. Install Single–Unit Rack Mount Bracket on opposite side from Rack Mount
Extruded Ear using the two (2) panhead SEMS screws, 6-32UNC-2A x .25”
supplied in the kit.
6. Install Rack Mount Extruded Ear on end of Single–Unit Rack Mount Bracket
using the two (2) existing truss head screws.
7. Position one of the two Chassis Rack Mount Brackets on the chassis side of the
rack, using one of the two (2) Right Angle Adapter Brackets, if required to match
existing vertical rack rail positions.
CAUTION
To prevent internal damage, use the specified screw lengths only.
Use caution when installing unit, the unit will not stay on Chassis
Rack Mount Bracket until at least one of the four (4) front panel
mounting screws is installed. See Figure 2-2.
