12
ELECRICAL REQUIREMENTS
A GROUNDED RECEPTICAL MUST BE USED, MAKE SURE THAT THE
RECEPTICAL MATCHES THE MACHINE REQUIREMENTS
MODEL VOLTS AMPS PLUG WATTS
PL1200HP 120 20 *
PL227 120 20 *
PL227HP 240 20 L6-20
PL238 120 20 *
PL238wf 240 20 L6-20
PL244wf 240 25 L6-30
*Conventional plug however the outlet must be dedicated (no other devices on the same circuit).
The electrical installation must meet local and federal electrical codes and a qualified person must
make the installation.
If a laminator is hard wired you must install a “disconnect” switch
!!! These Requirements must be strictly adhered to, as an incorrect installation will void your
warranty!!!
